Ideal for distortion-free joins on thin materials
Spark-Free Welding Performance
Optimized for Thin Gauges & Fine Wires
100% copper core for stable output & overload protection
| Model | DNKD-25 | DNKD-35 | DNKD-40 |
| Rated Voltage | 380V, 2 Phase, 50/60Hz | 380V, 2 Phase, 50/60Hz | 380V, 2 Phase, 50/60Hz |
| Rated Capacity | 25kVA | 35kVA | 40kVA |
| Short Circuit Current | 15000A | 17000A | 19000A |
| Electrode Distance | 100mm | 100mm | 100mm |
| Arm Length | 450mm | 450mm | 450mm |
| Duty Circle | 20% | 20% | 20% |
| Welding Capacity (mild steel wire) | 8.0mm+8.0mm | 9.0mm+9.0mm | 10.0mm+10.0mm |
| Welding Capacity (mild steel sheet) | 2.5mm+2.5mm | 3.5mm+3.5mm | 3.8mm+3.8mm |
* Swipe left/right or scroll horizontally to view complete specifications.
Intuitive interface with the function of slow current rise. Designed for precision and ease of use, ensuring seamless operation even for extended periods.
Manufactured with pure T2 grade copper electrode to ensure the highest welding quality and longevity. Perfect for both industrial and precision applications.
All red copper transformer construction guarantees stable operation and minimal energy loss. The heart of our machine, delivering durable and consistent performance.
Advanced single chip integrated full digital control system providing unmatched precision. Customizable parameters for different materials and applications.
Ergonomic pedal design with simple traction technology to make welding operations more intuitive and less fatiguing during extended work sessions.
