Ideal for galvanized can/tank
Copper wire electrodes | Reduced zinc vapor contamination
Precise HAZ control | Critical for coating integrity
Spatter-free seams | Smooth weld appearance
Low consumption design | Cost-efficient operation
| Model | FN-50QTSZ | FN-75QTSZ |
| Rated Voltage | 380V, 3 Phase, 50/60Hz | 380V, 3 Phase, 50/60Hz |
| Rated Capacity | 50kVA | 75kVA |
| Welding Capacity (galvanized iron sheet) | 0.8mm+0.8mm | 0.6mm+0.6mm |
| Arm Length | 500mm | 1000mm |
| Max. Electrode Pressure | 6100N | 6100N |
| No-load Voltage | 5.6V | 5.6V |
| Duty Circle | 50% | 50% |
| Max. Welding Current | 13000A | 18000A |
* Swipe left/right or scroll horizontally to view complete specifications.
